Schneider Electric ATV12HU15M2 VFD: Complete Specifications, Features, and Buying Guide

When deciding on a single-phase industrial solution, the Schneider Electric ATV12HU15M2 VFD is something worth closely looking at if you are in need of a compact, reliable and cost-effective drive. The Altivar 12 is from the widely known family of variable frequency drives, designed for simple machines that require basic yet reliable speed control without excessive options. This guide takes you through the specifications, features, applications and buy considerations for the Schneider Electric ATV12HU15M2 VFD while explaining why buying from a credible industrial automation supplier is just as important as purchasing the drive itself.

See full pricing and stock information on this drive on the product page at electrosynclimited.

What Is the Schneider Electric ATV12HU15M2 VFD?

The Schneider Electric ATV12HU15M2 VFD 1.5 kW (2 HP) variable speed drive comes from a single-phase 200–240 V AC supply and provides three-phase output to operate standard asynchronous motors. Altivar 12, which is designed for small, simple machines rather than big industrial process lines. By integrating sensorless flux vector control with a standard V/F (volts-per-hertz) mode, installers can serve either smooth, high-torque operation or a more basic open-loop control strategy within the same inverter depending on job conditions.

It is common at facilities, workshops, and smaller production lines where there is no access to three-phase power and three-phase motors are still needed. This drive is rated for single-phase input while consuming a O-P-O output.

Core Identity of the Drive

• Range: Altivar 12 (ATV12 series)

• Model reference: ATV12HU15M2

• Power rating: 1.5 kW / 2 HP

• Supply: Single-phase, 200–240 V AC (−15% to +10%)

• Output current: 7.5 A nominal (up to 14.9–17.8 (depending on the overload class)

• Enclosure rating: IP20

• Communication protocol: Modbus

Key Specifications of the Schneider Electric ATV12HU15M2 VFD

Understanding the technical specifications is essential before selecting any drive for a motor application. Below is a breakdown of what makes this unit suitable for light and medium industrial duty:

Electrical Ratings

• Input voltage: 200–240 V AC, single phase

• Output: Three-phase variable voltage and frequency

• Rated output power: 1.5 kW (2 HP)

• Output frequency range: 0.5 Hz to 400 Hz, field-adjustable

• Integrated EMC filter (Class C1) for reduced electromagnetic interference

Physical and Mechanical Details

• Dimensions: approximately 142 mm x 156.2 mm (without EMC conformity kit)

• Mounting: DIN rail or panel/wall mounting

• Enclosure protection: IP20

• Built-in cooling fan for thermal management

• Compact housing suitable for tight electrical cabinets

Protection and Safety Features

• Electronic thermal protection for the motor

• Overload and short-circuit protection

• Overvoltage and undervoltage protection

• Optional braking resistor support for high-inertia loads

Features That Make the Schneider Electric ATV12HU15M2 VFD Stand Out

Not every drive on the market balances simplicity and performance the way this one does. Here are the standout features worth highlighting.

Sensorless Flux Vector Control

This drive can deliver strong starting torque, typically in the range of 150–170% of the nominal motor torque, without requiring a feedback sensor. That makes it well suited to applications with variable load conditions.

Integrated EMC Filter

The integrated Class C1 EMC filter allows the drive to comply with stringent electromagnetic compatibility requirements, reducing electrical noise that can impact nearby SMT-able equipment.

User-Friendly Programming

Setup and viewing aren't more difficult than an LED display and buttons on a front panel can make them, even for journeyman technicians who aren't automation specialists. A serial / multi-loader option permits configuration settings to be transferred between drives, reducing the set-up time associated with multi-machine installations.

Energy-Efficient Operation

The drive balances power delivery to the motor based on its load, which can help ensure efficiency in variable-speed operation, reducing wasted energy.

Applications of the Schneider Electric ATV12HU15M2 VFD

Because it is purpose-built for simple machines, this drive fits a wide range of everyday industrial and commercial tasks, including:

• Conveyors and material handling systems

• Packaging equipment

• Commercial kitchen equipment

• Positive displacement pumps

• Mixers and agitators

• Small hoists and traction drives

• Fans and simple HVAC equipment

• Door control systems

Benefits of Choosing the Schneider Electric ATV12HU15M2 VFD

How to Control 3-Phase Motor with Power of Single Phase

The most important advantage of this drive is that it allows a facility that does not have three-phase power to run a three-phase motor, thus saving the cost of running new three-phase power lines.

Compact, Cabinet-Friendly Footprint

Small size allows integration into existing electrical panels without a total redesign of the enclosure layout.

Lower Total Cost of Ownership

The drive minimises energy spending and the risk of expensive downtime due to electrical faults with its efficient energy use, built-in protection features, and simple setup process.

Genuine Support from an Established Manufacturer

The Altivar 12 series is backed with a standard contract warranty period, adding confidence in long-lasting reliability to buyers and Schneider Electric's name as one of the most recognisable names in industrial automation and electrical distribution.

Installation and Wiring Guidance

While a qualified electrician or automation technician should always perform the final installation, here is a general overview of the process for the Schneider Electric ATV12HU15M2 VFD:

1. Using standard mounting brackets, you could securely mount the drive on a DIN rail and leave enough room for airflow.

2. Ladies and gentlemen, Reconnect the AC input power (200–240 V) to the inputs.

3. Wires three-phase output terminals to the motor based on terminal markings on the unit.

4. For loads with high inertia or for rapid deceleration, optional external braking can be connected to the dedicated braking terminals.

5. Before initiating the connected motor, define basic settings (including frequency range, motor nameplate data and control mode) at the front-panel display.

6. If the drive is used in facilities with equipment sensitive to voltage surges, it should help mitigate harmonics and protect the drive from transient voltages by considering adding a line reactor.

Incorrect wiring is crucial to never get the Schneider Electric ATV12HU15M2 VFD working properly, and therefore, always perform a full reference to the official Schneider Electric installation manual for full wiring diagrams and safety precautions specific to your particular installation.

Why Buy the Schneider Electric ATV12HU15M2 VFD from ElectroSync Limited

The choice of the suppliers for industrial drives is of equal importance to selecting the appropriate equipment. Our company offers its clients the opportunity to buy authentic Schneider electric components, technical information, and professional help from the expert team.

Here is what sets Electrosync Limited apart as a sourcing partner:

• Authenticity: Every unit listed on electrosynclimited is sourced through verified supply channels, reducing the risk of counterfeit or grey-market components.

• Technical Support: The team at Electrosync Limited can help confirm compatibility with your existing motor and control setup before you order.

• Fast Fulfilment: Electrosync Limited is structured to process industrial orders efficiently, which matters when a facility needs a replacement drive quickly to minimise downtime.

• Transparent Documentation: Product pages on electrosynclimited include specification sheets so buyers can confirm ratings before purchase.

You can view current availability and place an order directly through the ATV12HU15M2 product page on electrosync.limited.

Frequently Asked Questions

Is the Schneider Electric ATV12HU15M2 VFD suitable for three-phase motors?

Yes. It accepts single-phase input power and delivers a three-phase output, making it a practical solution for running standard three-phase asynchronous motors where only single-phase supply is available.

What is the maximum motor power this drive supports?

It is rated for 1.5 kW (2 HP), which fits typical light-industrial and commercial machinery applications.

Does it require a separate braking unit?

A braking resistor is optional and only needed for applications involving high-inertia loads or fast stop requirements.

Where can I confirm current stock and pricing?

You can check availability directly on Electrosync Limited through the dedicated product listing page.

Conclusion

One of the basic & functionally flexible single-phase to three-phase VFDs is the Schneider Electric ATV12HU15M2, which has a compact design and sensorless flux vector control that makes it a reliable choice for many simple machine applications. Get this model if you are replacing an old drive or specifying equipment for a new installation, balancing high performance with easy configuration and support. If you're really after stock accuracy instructions, as well as compass order completion, Electrosynclimited is still a feasible area for making your Schneider Electric ATV12HU 15M2 VFD and also similar associated mechanical computerisation contraptions.
